Universal anaerobic adhesive L2609
Elite-L2609 is one-component, low viscosity, high strength anaerobic cylinder-components curing agent hardening with excellent chemical resistance. The product is applied between two close metal surface, curing under the condition of air isolation.
The product is applied to fix and assemble bearings and sleeve matching components. It is used to cure the cylinder components whose maximum clearance diametral is 0.10mm. L2609, as the universal type, is applied to keys, axis, axle bearing, axle sleeve, threaded fastener,sand holes filling.
- Bonded material:
- Tensile strength(n/mm2):
- Primary fixation time(s):5min
- Temperature range(℃):-55-150
- Shore hardness(D):
- Application:Universal type. Fix and assemble keys, axis, axle bearing, axle sleeve, rotor axis of small motors and liner bushing.
|Average disassembling moment (N.m)||30|
|Breaking moment (N.m):||38|
|Primary curing time( min):||5min|
|Entire curing time(hrs):||24H|
Universal type. Fix and assemble keys, axis, axle bearing, axle sleeve, rotor axis of small motors and liner bushing.
The product was applied to axle bearing, axle sleeve and rotor axis of small motors:
