PLASTIC HIGH-STRENGTH BONDING, SHADOWLESS ADHESIVE T8021
Product Description
Elite-T8021 is toughening UV light curing adhesive, which is applied to bond plastics and metals. The product will cure into flexible adhesive, if it is exposed to the strong ultraviolet radiation or visible light. It also has the properties of strong impact resistance and good anti-stripping ability.
Properties
T8021 is applied to high-strength bond plastics, PC, PMMA and glass.
High-flexibility
Application
- High-strength bond plastics and EPC.
- Assemble and reinforce electronic components.
Product Data:
|
The light source was a UV intensity of 100mW/cm2 and a wave length of 375nm medium pressure. |
|
|
mercury lamp. The control error was less than 0.005 inches（0.012 mm). |
|
|
Elongation at break[%](ASTM D412-61T):[%](ASTM D412-61T) |
65% |
|
Shore hardness[D] |
55D |
| Shear strength [psi] (ASTM D-4501) |
50 |
| Temperature range[℃] |
-40～145oC |
|
Coefficient of thermal expansion （ASTM D696） |
82X10-6 |
|
Thermal conductivity[W/mK] |
0.2 |
| Coefficient of water absorption（ASTM D570） |
0.7% |
|
Surface resistance[&] (ASTM D149) |
1.4X108 |
|
Volume resistivity [W.cm] |
6.09X1014 |
| Dielectric strength[kV/m]（ASTM D257） |
19 |
