GLASS-GLASS, PLASTIC-GLASS BONDING, SHADOWLESS ADHESIVE T3046
Product Description
Elite-T3046 is one-component, UV light curing, acrylate adhesive, which is applied to touch screen instead of OCA tape. It has good properties of good adhesion, low mold shrinkage, excellentlight transmittance and goodweather resistance.
Properties
- Excellent adhesion to glass and PET substrates.
- The adhesive layer has good properties of excellentlight transmittance, shock resistance and excellent stability.
- It has good properties of low mold shrinkage
- excellent good weather resistance
- anti-yellowing capacity
- low smell
- Visible-Light curing.
Product Data：
|
Test projects |
Teat approaches | Data |
| Appearance | Visual Inspection | Colorless, transparent fluid |
| Viscosity [mPa.s] | NDJ-1 rotating viscometer，25℃，20rpm,spindle #3 |
1000-1500 mPa.s |
| Density | Uncured Adhesive at 25℃ | 0.97g/cm3 |
| Curing condition | UVA：250 to 420nm | 1800-2200mj/cm2 |
| Hardness | Shore hardness | 12A |
| Curing depth | Curd@100mW/cm2 for 30S | 4mm |
| Curing shrinkage rate | Density Meter | 0.2% |
| Primary curing time | Curd@100mW/cm2 |
>2s |
| Bonding strength |
Glass-Glass ross Bonding |
6.0N/mm |
| Dielectric constant | 1MHZ | 3.1 |
| Liquid refractive index | Abbe at 25℃ | 1.49 |
| Solid refractive index | Abbe at 25℃ | 1.50 |
| Light transmittance% | At 550nm | 99.9% |
| Haze | ASTM D1003 | 0.15% |
| Yellowness index | DSTM D1925/C2 | 0.30 |
The product was applied to home screen of electrical appliances：
